Large-Head-Distance Side-Mounted Laser Unit
Key Features:
1.Mounted on the side of the needle bar frame for simple setup.
2.Suitable for embroidery machines with head spacing of 220 mm or more.
3.Optional under-table smoke extraction and automatic waste collection system available for cutting thicker materials such as PU and denim
Glass Tube Specifications:
1.Power: 45W / 55W / 65W
2.Dimensions: 67 × 68 × 766 / 900 / 1050 mm
3.Weight: 2.2 / 2.5 / 2.8 kg
4.Power Stability: ≤ ±5%
Conventional sensors struggle to cover head pitches exceeding 300mm, causing missed thread breaks during wide-span embroidery. The hanging mount with extended-span brackets ensures precise monitoring at every needle position without blind spots.
Large-format machines suffer from cable tangling and interference due to excessive wiring lengths. The side-hanging modular design shortens fiber paths, reducing mechanical interference risks and enhancing system stability.
9-needle and 12-needle machines require time-consuming individual head calibration. The hanging structure enables rapid positioning installation, significantly reducing maintenance downtime and thread-change interruptions.
